NCF 2334 ECJB/PEX

Product Attributes

Part Number	NCF 2334 ECJB/PEX
System of Measurement	Metric
Roller Bearing Type	Cylindrical
For Load Direction	Combined Radial and Thrust
Construction	Single Row
Inner Ring Type	With Inner Ring
Seal Type	Open
Bore Dia	170 mm
Bore Dia Tolerance	-0.025mm to 0
Outer Dia	360 mm
Outer Dia Tolerance	-0.04mm to 0
Width	120 mm
Width Tolerance	-0.25mm to 0
Shoulder Diameter Inner Ring	234.6 mm
Shoulder Diameter Outer Ring	300.2 mm
Raceway Diameter Outer Ring	316 mm
Chamfer Dimension r1,2(min.)	4 mm
Permissible Axial Displacement(max.)	10 mm
Ring Material	52100 Chrome Steel
Roller Material	52100 Chrome Steel
Cage Material	Sheet steel cage, inner ring centred
Dynamic Load Rating	1760 kN
Static Load Rating	2200 kN
Max Speed (X1000 rpm)	3
Lubrication	Grease, Oil
Temperature Range	-30° to 110 °C
RoHS	Compliant
REACH	Compliant
Weight	58.5 kg
