| Part Number | 3212 ATN9 |
| Interchange | 5212 |
| System of Measurement | Metric |
| Bearing Type | Ball |
| Internal Design | High Speed |
| For Load Direction | Combined Radial and Thrust |
| Construction | Double Row |
| Seal Type | Open |
| Bore Dia | 60 mm |
| Bore Dia Tolerance | -0.012mm to 0 |
| Outer Dia | 110 mm |
| Outer Dia Tolerance | -0.013mm to 0 |
| Width | 36.5 mm |
| Width Tolerance | -0.05mm to 0 |
| Shoulder Diameter Inner Ring (Large Side Face)(d1) | 74.459 mm |
| Shoulder Diameter Outer Ring (Large Side Face)(D1) | 96.2 mm |
| Chamfer Dimension (r1 2)(min) | 1.5 mm |
| Distance Pressure Point (a) | 63 mm |
| Ring Material | 52100 Chrome Steel |
| Ball Material | 52100 Chrome Steel |
| Cage Material | Polyamide(PA66) |
| Dynamic Radial Load | 75 kN |
| Static Radial Load | 64 kN |
| Max Speed (X1000 rpm) | 5.6 |
| Lubrication | Lubricated |
| Temperature Range | -30° to 110 °C |
| ABEC Rating | P6 (ABEC-3) |
| ROHS | Compliant |
| REACH | Compliant |
| Weight | 1.2 kg |
